Distributing Items
| CARBON STEEL PIPE | |
|---|---|
| TYPE | EAMLESS PIPE & TUBE (SMLS) |
| ELECTRIO RESISTENCE WELDING PIPE (ERW) | |
| ONGDITUDINALLY SUB-MURGED ARC WELDING PIPE (LSAW) | |
| SPIRALLY SUB-MURGED ARC WELDED PIPE (SSAW) | |
| GALVANIZED PIPE (GALV) | |
| COATING (INTERNAL & EXTERNAL) | |
| SIZE | SMLS 1/2" ~ 24" |
| ERW 1" ~ 24" | |
| SSAW 20" ~ 100" | |
| LSAW 26" ~ 140" | |
| GALV 1" ~ 24" | |
| SCH | SCH10 - XXS |
| STANDARD & GRADE |
APL 5L Gr X42 - 70 (PSL1, 2) |
| ASTM A53, A106 Gr.B | |
| ASTM A213 - A249 - A179 - A671 - A672 | |
| EN10025 (S235-S355) | |
| BUTTWELD FITTING | SIZE / SCH / DIMENSION | MATERIAL | |
|---|---|---|---|
| ELBOW | 90 DEG LR - SR |
1/2" - 24" SMLS
12" - 80" WELDED SCH10 - Up to OTHER THK (XXS) DIMENSION STANDARD ANSI - ASME - DIN |
C.S ASTM A234 WPB S.S A403 WP316L Welded 321 - 347 - L.H FLANGE A182 F316L BS EN1092-1 FL ANGE A105 A SME B16.5 FL ANGE A105 A SME B16.47 |
| 45 DEG | |||
| 180 DEG - RETURN | |||
| "BEND 90 - 45 - 60 -… 1D, 1.5D, 3D - 5D -…" | |||
| TEE | EQUAL TEE | ||
| REDUCING TEE | |||
| REDUCER | ECC & CONS | ||
| CAP | CAP OVAL | ||
| FLANGE | Slip on, WNRF and so on.. | ||
| DUCTILE IRON PIPE & FITTING | |
|---|---|
| TYPE | Ductile Iron Pipe (ISO2531, BS4772) K9 or C-Class |
| All Flanged Tee, Double Flanged Bend, Flanged Socket, Double Flanged Taper, Ductile Iron Pipes with Integrally Cast Flanges, Flanged Bellmouth, - ISO2531, K14, PN10 / PN16 / PN25 |
|
| Dimension of Flange- ISO2531, BS EN 545, ISO 7005-2 | |
| Double Socket Taper, Double Socket Bend, MJ Collar - ISO2531, K12 | |
| Double Socket Tee with Flanged Branch, All Socket Tee, Double Socket Level Invert Tee with Flanged Branch- ISO2531, K14 |
|
| Dismantling Adaptor, Flanged Adaptor, Flanged Adaptor - ISO2531, PN10 / PN16 / PN25 |
|
| JOINT | Mechanical Joint (K-Type), Push On Joint (T-Type), Restrained Joint Type |
| SIZE | DN 80 - DN 2600 |
| COATING | External (ISO8179) : Metallic Zinc with Bituminious Paint, Epoxy Painting, Aluminium Power Painting, Polyurethane, FBE (Fusion Bonded Epoxy) |
| Internal (ISO4179) : Cement Mortar Lining, Epoxy Powder Lining, Ceramic Epoxy Lining, Polyethylene Lining, FBE (Fusion Bonded Epoxy) |
|
| STAINLESS STEEL PIPE | |
|---|---|
| TYPE | SEAMLESS STAINLESS STEEL TUBE & PIPE |
| WELDED STAINLESS STEEL PIPE | |
| HIGH PRESSURE PIPE | |
| SIZE | EFW - ERW 1/2" - 24" |
| SMLS 1/2" - 24" | |
| SCH | SCH 5S - SCH 80S & OTHER THK |
| STANDARD & GRADE |
ASTM A312 - TP304 - 310 - 316 - 321 - 347 (L/H) |
Coating
(Pipe & Fitting)
| Division | Coating Produce | Application |
|---|---|---|
| External & Internal |
Polyethylene 3-Layer FBE(Fusion Bonded Epoxy) Liquied Epoxy |
AWWA C210, C213, C222 DIN 30670 KS D3565, D3626 |
